With the ability to lift into orbit over 54 metric tons (119,000 lb)--a mass equivalent to a 737 jetliner loaded with passengers, crew, luggage and fuel--Falcon Heavy can lift more than twice the payload of the next closest operational vehicle, the Delta IV Heavy, at one-third the cost.
Images
Specifications
{
"height": {
"meters": 70,
"feet": 229.6
},
"diameter": {
"meters": 12.2,
"feet": 39.9
},
"mass": {
"kg": 1420788,
"lb": 3125735
},
"first_stage": {
"thrust_sea_level": {
"kN": 22819,
"lbf": 5130000
},
"thrust_vacuum": {
"kN": 24681,
"lbf": 5548500
},
"reusable": true,
"engines": 27,
"fuel_amount_tons": 1155,
"burn_time_sec": 162
},
"second_stage": {
"thrust": {
"kN": 934,
"lbf": 210000
},
"payloads": {
"composite_fairing": {
"height": {
"meters": 13.1,
"feet": 43
},
"diameter": {
"meters": 5.2,
"feet": 17.1
}
},
"option_1": "dragon"
},
"reusable": false,
"engines": 1,
"fuel_amount_tons": 90,
"burn_time_sec": 397
},
"engines": {
"isp": {
"sea_level": 288,
"vacuum": 312
},
"thrust_sea_level": {
"kN": 845,
"lbf": 190000
},
"thrust_vacuum": {
"kN": 914,
"lbf": 205500
},
"number": 27,
"type": "merlin",
"version": "1D+",
"layout": "octaweb",
"engine_loss_max": 6,
"propellant_1": "liquid oxygen",
"propellant_2": "RP-1 kerosene",
"thrust_to_weight": 180.1
},
"landing_legs": {
"number": 12,
"material": "carbon fiber"
},
"payload_weights": [
{
"id": "leo",
"name": "Low Earth Orbit",
"kg": 63800,
"lb": 140660
},
{
"id": "gto",
"name": "Geosynchronous Transfer Orbit",
"kg": 26700,
"lb": 58860
},
{
"id": "mars",
"name": "Mars Orbit",
"kg": 16800,
"lb": 37040
},
{
"id": "pluto",
"name": "Pluto Orbit",
"kg": 3500,
"lb": 7720
}
],
"flickr_images": [
"https://farm5.staticflickr.com/4599/38583829295_581f34dd84_b.jpg",
"https://farm5.staticflickr.com/4645/38583830575_3f0f7215e6_b.jpg",
"https://farm5.staticflickr.com/4696/40126460511_b15bf84c85_b.jpg",
"https://farm5.staticflickr.com/4711/40126461411_aabc643fd8_b.jpg"
],
"name": "Falcon Heavy",
"type": "rocket",
"active": true,
"stages": 2,
"boosters": 2,
"cost_per_launch": 90000000,
"success_rate_pct": 100,
"first_flight": "2018-02-06",
"country": "United States",
"company": "SpaceX",
"wikipedia": "https://en.wikipedia.org/wiki/Falcon_Heavy",
"description": "With the ability to lift into orbit over 54 metric tons (119,000 lb)--a mass equivalent to a 737 jetliner loaded with passengers, crew, luggage and fuel--Falcon Heavy can lift more than twice the payload of the next closest operational vehicle, the Delta IV Heavy, at one-third the cost.",
"id": "5e9d0d95eda69974db09d1ed"
}
